The A14 Outdoor 8 inch speaker column delivers versatile acoustic performance optimized for open-air installations. Featuring configurable power tiers (40W/60W/90W/120W), it supports adaptive deployment from intimate courtyards to large-scale venues.
Technical Highlights
Voltage Compatibility: Operates on 70-100V distributed systems with ±10% tolerance, maintaining signal integrity over extended transmission lines
Full-Range Clarity: 200Hz-15kHz frequency response ensures precise reproduction of both voice announcements and music content
High-Efficiency Output: 92-95dB SPL (@1W/1m) enables clear audio projection in noisy outdoor environments
Physical Specifications
Configuration Dimensions
1×8" Unit 250×430 mm
2×8" Units 250×665 mm
3×8" Units 250×905 mm
4×8" Units 250×1320 mm
The modular enclosure design with IP-rated weatherproof construction ensures durability across temperature extremes (-30°C to +60°C), ideal for permanent installations in transportation hubs, public squares, and stadiums.
Product Specifications
|
Model |
A14 |
|||
|
Rated power |
40W |
60W |
90W |
120W |
|
Input voltage |
70/100V |
|||
|
Frequency range |
200-15KHz |
|||
|
SPL(@1W/m) |
92dB |
93dB |
94dB |
95dB |
|
Speaker unit |
1x8" |
2x8" |
3x8" |
4x8" |
|
Dimension (WxH)mm |
250X430 |
250X665 |
250X905 |
250X1320 |
